The 2026 Raven Boards SPEC & SIZES
Available in customizable sizes from 65 Litres right up to 130 litres. Please tell us your ideal dimensions and we 'tweak' the raven shape to suit - These boards are CNC cut and we can cut them in any literage and reproduce exactly the same board scaled up or down.
The Base board is designed at 82L - Its 6'3 x 19.5" Wide and 4.8" Thick
For example -
The Same board in 86L is 6'4 x 193/4' Wide and 5" Thick.
SPECS
Typical Weights of the boards with Deck grip fitted is around 4 kgs or less. Construction is EPS foam Sandwich with HD Foam TWIN stringers. You can also opt for 'Pro' glassing - we use 1 layer less glass on the deck to remove a further 500Gramms weight...This can increase knee dents over time, and is only reccommended if your OK with this.
MAST TRACK BOX
Were using a Foil Tech 450mm Track box, (14") sunken into 4 x 120cm long High density Twin rail track HD Foam rail that runs right through to the deck for Ultimate connection to foil and board strength and Stiffness.
CONSTRUCTION :
Biaxial Twin weave Stitched Carbon Fibre - Not to be confused with typical 'Twill' carbon fibre - The Biax we use is stiffer / stronger than any other substance on the planet. Its expensive and hard to work with. But its stiffness is INSANE.
Vent Plugs included in all boards, as well as a rear leash plug. Foot straps / Foot strap inserts add weight and are able to be added in if desired - See the sales options on the listing for 'extras' - If your adding footstraps we need accurate measurements of your stance and ride positioning of your feet.
TO RIDE - WHATS DIFFERENT? WHY ?
Swing weight is almost un-noticable as these boards place the rider almost midships, the Pump is insane with the Front and rear foot connected twin stringers transferring 100% of your pump energy directly through the foil.
Getting exactly the right size is important. Our team riders are riding these boards approximatly 10 Litres below their body weight. This allows the board to pump up onto foil the best - with downforce pushing the board into the water deeper to return hard for the next pump - you get maximum foil thrust to get up .
The slight bias towards sinking also gives the board maximum stability in choppy water, while the bulb nose takes care of water coming over the nose while pumping hard - any penetrations into chop will keep the nose lifting while maintaining a flat as possible profile for speed.
The Raven Range is Designed for 'Bounce up launch to foil - this is achieved by its dramatic bevels and enhanced tail rocker, a small step in the tail helps 'release' and the bulbous nose allows a flatter board when moving through the chop without risk of nosedives.
Super Ace as light wind Wing Foil board , Parawing machine and Point Break Prone board.
